Dongguan Sourcechip Opto-electrical Tech Co.,Ltd. is a long-term supply of high-quality LED lamps Chinese manufacturers. We have 12 years of history in the LED lighting industry. We have a wealth of experience in production and development. The 8 inch recessed led down light is not only high quality components, and production processes and performance testing is very strict, quality of each product are guaranteed. The 8 inch recessed led down light performance below. If you need the 8 inch recessed led down light, you can contact us by e-mail.
xinxinlong001
Dongguan Sourcechip Opto-electrical Tech Co.,Ltd.
Sourcechip LED down light maker Tel: +86-769-81608082
Sourcechip LED down light maker Fax: +86-769-81608083
Sourcechip 8 inch recessed led down light Contact E-mail:
Sourcechip 8 inch recessed led down light website 1:
Sourcechip 8 inch recessed led down light website 2:
Sourcechip LED down light maker Address: No.2 Min Yi Road, Wusha Community, Chang'an Town, Dongguan, Guangdong, China
1.LED DownlightDetails
2.Product material
Lamp body | Diffusive lampshade | light source | Driver | Finish |
aluminum alloy | Light transmittance≥85% | COB | wide Input driver EMC approved | white/black |
3. Specification
Model No. | SC-DLB030W01-30 | SC-DLB030W01-40 | SC-DLB030W01-60 |
Rated power | 26W |
Consume power | 30±2W |
Input Voltage | AC 100-240V |
Output Voltage | 32-42V |
Input current | 720mA±5% |
Efficiency | ≥85% |
Cutout | 198mm |
P.F | ≥0.9 |
Light Source CRI | Warm white | Natural white | Pure white |
3000±200k | 4000±300k | 6000±300k |
Light Source Luminous flux(lm) | ≥2500LM | ≥2650LM | ≥2750LM |
Lighting CCT | 3000±300k | 4000±300k | 6000±500k |
Lighting LM | 2400±250LM | 2450±250LM | 2550±250LM |
Lighting View Angle | 90° |
Lighting CRI | ≥70/≥80 |
Key point temperature
(during aging test) | LED Welding foot | Lamp shell |
≤75°C | ≤70°C |
Working Temp. | -10°C~40°C / R.H.≤85% |
Storage Temp. | -30~65°C |
Life span | 50,000 HR |
IP Rate | IP20 |
4.Application
Offices, shopping mall, supermarket, schools, hospitals, hotels, parking lot, factories, municipal engineering, houses etc.
5.Payment
We accept PayPal, T/T, L/C,Western union, Escrow etc .If need further detail, Please feel free to contact us, Thanks!
6.Shipment
We ship by commercial express,Air freight,Ship.
7.Packing, transportation & storage requirement
8.1, Packing Material
Name | Description | QTY |
|
|
PE bag | 380*350mm | 1pcs | / | 20±5g |
White box | 230*230*100mm | 1pcs | N.W | 1280±30g/1PCS |
Big carton case | 515*475*480mm | 1/20pcs | G.W | 25.65±0.5kg/carton |
8.2, Pasted Master Carton label on each main mark and side mark, pasted product label on Lights;
8.3,Seal packing box tight before transport, handle gently, mark product name, quantity etc on carton box;
8.4,Storage requirement: moisture proof,dust proof, avoid press, avoid tumble, avoid acid and base, avoid direct sunshine and expose;
8.5,storage expires: One year. exceed the expire time must Re-inspect electricity function before use.
